Single Leg Wire Rope Slings

Get a Price/Quote

Product Details:

Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Product Description

Wire rope slings are the most popular in the industry due to its features of Durability, Versatility, and availability in broad range of various working load limits (WLL). A single part sling is made of single wire rope with end fittings of different types. We manufacture and supply wire rope slings made of tested quality wire ropes as per IS 2762-1982 specifications and mechanical ferule spliced as per IS: 5245 (Part-II) or Hand spliced as per IS: 5245 (Part-I).

	MAX. SAFE WORKING LOAD IN KG FOR SINGLE PART WIRE ROPE SLINGS
Catalogue Code	MIN. ROPE SIZE (MM)	VERTICAL LIFT (KG)	BASKET LIFT (KG)		CHOKER LIFT (KG)
WRS-3	3	70		140	50
WRS-4	4	130		260	100
WRS-5	5	200		400	150
WRS-6	6	250		500	190
WRS-8	8	550		1100	410
WRS-9	9	670		1340	500
WRS-10	10	800		1600	600
WRS-11	11	1000		2000	750
WRS-12	12	1200		2400	900
WRS-13	13	1400		2800	1050
WRS-14	14	1750		3500	1300
WRS-16	16	2000		4000	1500
WRS-18	18	2500		5000	1875
WRS-19	19	3000		6000	2250
WRS-20	20	3300		6600	2475
WRS-22	22	4000		8000	3000
WRS-24	24	4600		9200	3450
WRS-25	25	5000		10000	3750
WRS-29	29	6500		13000	4875
WRS-32	32	8000		16000	6000
WRS-35	35	9200		18400	6900
WRS-36	36	10400		20800	7800
WRS-38	38	12000		24000	9000
WRS-40	40	12700		25400	9525
WRS-44	44	16700		33400	12525
WRS-48	48	20000		40000	15000
WRS-52	52	23000		46000	17250
